Vacuum Pads (Vacuum Suction Cups)
Mark-free Pad (Vacuum Suction Cup) ZP2
-
?For use where adsorption marks must not be left on workpieces
?Pad which reduces the number of adsorption marks left on workpieces by the rubber
-
2D/3D CAD
The new SMC CAD SYSTEM, CADENAS, allows you to output 2D/3D CAD data with full part numbers in various data formats. Responses to part number selection has been greatly improved with the newly developed system.
Click here for 2D/3D CAD2D CAD
Click here for 2D CAD
Safety Instructions Vacuum Equipment/Precautions Vacuum Pads/Precautions Series Variations Model Selection Standard: Mounting Bracket Assembly (p.121-130) High Rigidity: Mounting Bracket Assembly (p.255-263) Green Procurement (RoHS)
| Series | Pad form | Pad diameter(mm) |
|---|---|---|
| ZP2 | Flat type | φ4,φ6,φ8,φ10,φ13,φ16, φ20,φ25,φ32,φ40,φ50 |
| ZP2 | High rigidity (Flat type with ribs) | φ40,φ50,φ63,φ80,φ100,φ125 |
| ZP2 | Resin attachment | Applicable pad: φ6,φ8,φ10,φ13, φ16,φ20,φ25,φ32 |
Features
■For use where adsorption marks must not be left on workpieces
Application example
:Suction transport of glass substrate
?Solar cell manufacturing equipment
?Semiconductor manufacturing equipment
?FPD production equipment etc
■Minimizes the transfer of rubber constituents to workpieces
■Variations
