WEB Catalog

Product Information ?  WEB Catalog  ? Electric Actuators/Cylinders  ? Manifold Controller/Manifold Controller Compatible Electric Actuator

Manifold Controller/Manifold Controller Compatible Electric Actuator

Battery-less Absolute Encoder Type
[Compatible with Manifold Controller]
Electric Actuator/Rod Type LE2Y□H

    · Compatible with manifold controller
    · Annual CO2 emissions reduced by up to 38% through motor control
    　optimization (SMC comparison)
    　8.7 kg-CO2e/year (14.1)
    　? The numerical values vary depending on the operating conditions.
    · Battery-less absolute encoder type
    　Restart from the last stop position is possible.
  • 2D/3D CAD

    The new SMC CAD SYSTEM, CADENAS, allows you to output 2D/3D CAD data with full part numbers in various data formats. Responses to part number selection has been greatly improved with the newly developed system.

    Click here for 2D/3D CAD
  • Battery-less Absolute Encoder Type
    [Compatible with Manifold Controller]
    Electric Actuator/Rod Type LE2Y□H
    Manual
    Model View search result
    LE2Y16□HView search result
    LE2Y25□HView search result
    LE2Y32□HView search result
  • Battery-less Absolute Encoder Type
    [Compatible with Manifold Controller]
    Electric Actuator/Rod Type LE2Y□H
    DoC
    Model View search result
    LE2Y16□HView search result
    LE2Y25□HView search result
    LE2Y32□HView search result
SpecificationModelStroke
(mm)		Work load (kg)
Horizontal		Speed
(mm/s)		Screw lead
(mm)
Battery-less absolute
(Step motor 24 VDC)		LE2Y16□H30 to 300Max. 40Max. 7002.5，5，10
Battery-less absolute
(Step motor 24 VDC)		LE2Y25□H30 to 400Max. 70Max. 9003，6，12，20
Battery-less absolute
(Step motor 24 VDC)		LE2Y32□H50 to 500Max. 100Max. 9004，8，16，24

Features

Manifold Controller up to 16 axes can be connected

Annual CO2 emissions reduced by up to 38% through motor control optimization (SMC comparison)

Select from 5 cable entry directions

Restart from the last stop position is possible.

Detection of table stop position by means of an auto switch is possible.
