Pressure Switches
- Energy Saving
- By Industry ⁄ Process
- Applications
Application Example
Liquid coolant pressure control
Application Examples
Confirmation of supply pressure of cleaning lines
Confirmation of working pressure of hydraulic cylinder
3-Screen Display High-Precision Digital Pressure Switch
ISE7□/7□G/79S
Switches/Sensors/Controller ? Electronic Pressure Switches/Sensors (Self-contained Type)IO-Link Devices ? Pressure Switches
Industrial Device Communication Equipment/Wireless System ? Industrial Device Communication Equipment: IO-Link Compatible Products
-
?It is possible to change the settings while checking the measured value.
?IO-Link
?Angled display
Good visibility from various mounting positions
?Rotating display
Display can rotate 336 degrees after installation
?Applicable fluid：Air, Non-corrosive gas, Non-flammable gas (ISE70/71)
：Liquid or gas that will not corrode materials of parts
in contact with fluid (ISE7□G/79S)
Safety Instructions Pressure Switches/Flow Switches/Precautions
Pressure Switch Series Variations/Application Example Glossary of Terms/Technical Information
Green Procurement (RoHS)
Pressure Switch Series Variations/Application Example Glossary of Terms/Technical Information
Green Procurement (RoHS)
| Series | Type | Rated pressure range |
|---|---|---|
| ISE70 | Positive pressure (For air) | 0 to 1MPa |
| ISE71 | Positive pressure (For air) | 0 to 1.6MPa |
| ISE70G | Positive pressure (For general fluids) | 0 to 1MPa |
| ISE75G | Positive pressure (For general fluids) | 0 to 2MPa |
| ISE76G | Positive pressure (For general fluids) | 0 to 5MPa |
| ISE77G | Positive pressure (For general fluids) | 0 to 10MPa |
| ISE78G | Positive pressure (For general fluids) | 0 to 16MPa |
| ISE79S | Positive pressure (For general fluids) | 0 to 50MPa |
2-Color Display Digital Pressure Switch ISE70/75（H）
Switches/Sensors/Controller ? Electronic Pressure Switches/Sensors (Self-contained Type)
-
?Metal body type (Aluminum die-casted)
?IP67
?With M12 connector
∗ The ISE70 series was discontinued in April 2018.
Please select the ISE70-□-L2 series.
∗ The ISE75 series was discontinued in July 2018.
Please select the ISE77G series.
∗ The ISE75H series was discontinued in December 2022.
Please select the ISE78G series.
Safety Instructions Pressure Switches/Flow Switches/Precautions
Pressure Switch Series Variations/Application Example Glossary of Terms/Technical Information
Green Procurement (RoHS)
Pressure Switch Series Variations/Application Example Glossary of Terms/Technical Information
Green Procurement (RoHS)
| Series | Type | Rated pressure range |
|---|---|---|
| ISE70 | Positive pressure (For air) | 0 to 1MPa |
| ISE75 | Positive pressure (For general purpose fluids) | 0 to 10MPa |
| ISE75H | Positive pressure (For general purpose fluids) | 0 to 15MPa |
Pressure Sensor/Switch for General Fluids PSE57□
Switches/Sensors/Controller ? Electronic Pressure Switches/Sensors (Remote Type)
-
?PSE Sensor Set Up Tool PSE-ST has been added. [New]
?Switch output specification
?IO-Link compatible
?Withstand voltage: 500 VAC
?Enclosure: IP65
?Materials of parts in contact with fluid
Piping port: C3604 + Nickel plating
Pressure sensor: Al2O3 (Alumina 96%)
O-ring: FKM + Grease (PSE570/573/574)
Square ring: FKM (PSE575/576/577)
Safety Instructions Pressure Switches/Flow Switches/Precautions
Pressure Switch Series Variations/Application Example Glossary of Terms/Technical Information
Green Procurement (RoHS)
Pressure Switch Series Variations/Application Example Glossary of Terms/Technical Information
Green Procurement (RoHS)
| Series | Type | Rated pressure range | Proof pressure |
|---|---|---|---|
| PSE570 | Positive pressure | 0 to 1 MPa | 3.0 MPa |
| PSE573 | Compound pressure | －100 to 100 kPa | 600 kPa |
| PSE574 | Positive pressure | 0 to 500 kPa | 1.5 MPa |
| PSE575 | Positive pressure | 0 to 2 MPa | 5.0 MPa |
| PSE576 | Positive pressure | 0 to 5 MPa | 12.5 MPa |
| PSE577 | Positive pressure | 0 to 10 MPa | 30 MPa |
2-Color Display Digital Pressure Sensor Controller PSE300
Switches/Sensors/Controller ? Electronic Pressure Switches/Sensors (Remote Type)
-
?Applicable sensors: PSE53m, 54m, 550, 56m, 570, 573, 574
?Compatible with voltage input and current input
?Response time: 1 ms
?Space saving, Capable of vertical and horizontal contact mounting
?Panel mounting, Bracket mounting, DIN rail mounting
? The PSE300 series is to be discontinued as to September 2025.
Please select the PSE300A series instead. ?Click here for details.
Safety Instructions Pressure Switches/Flow Switches/Precautions
Pressure Switch Series Variations/Application Example Glossary of Terms/Technical Information
Green Procurement (RoHS)
Pressure Switch Series Variations/Application Example Glossary of Terms/Technical Information
Green Procurement (RoHS)
| Series | Set pressure range |
|---|---|
| PSE300 | －101 to 101 kPa 10 to －101 kPa －10 to 100 kPa －0.1 to 1 MPa －50 to 500 kPa －0.2 to 2 kPa |
Compact Cylinder with Linear Guide MXZ
Air Cylinders ? Table Cylinders
-
?Compact: Overall length: 49.5 mm, Width: 30 mm
?The integration of the linear guide and the cylinder allows for reduced design and assembly time.
?Lightweight workpieces such as electronic boards can be stopped, positioned, and clamped.
?Port location selectable
?Auto switch mountable on 3 surfaces
Safety Instructions Actuators/Precautions
Auto Switches/Precautions Model Selection/Technical Data Green Procurement (RoHS)
Auto Switches/Precautions Model Selection/Technical Data Green Procurement (RoHS)
| Type | Series | Action | Bore size (mm) |
|---|---|---|---|
| Standard | MXZ | Double acting | 12, 16, 20, 25 |
