|7. Drying ? UV Irradiation
After drying and fixing the coating material to the film, UV irradiation is used to harden the surface.
Clean Room Specifications
| Use | Item name | Series |
|---|---|---|
| Pneumatic equipment for clean room |
Clean Series | Clean Series |
Preventing Attachment of Foreign Objects
| Use | Item name | Series |
|---|---|---|
| Anti-static electricity measures, clean blow |
Ionizer | IZS 40 / 41 / 42 |
| Clean blow | Clean Air Module | LLB |
Points and Precautions for Selection
? High temperatures can cause a charge to build up, resulting in generation of static electricity. Please use an ionizer to
prevent static electricity and the attachment or adhesion of foreign objects.
? When using in a clean environment, please select equipment that conforms to clean-room class standards of cleanliness.
Temperature Control of the UV Heat Source
| Use | Item name | Series |
|---|---|---|
| Temperature control | Thermo-cooler (Constant temperature water circulating device) |
HRS |
| Thermo-cooler (Constant temperature fluid circulating device <High performance type>) | HRZ |
