Compact Guide Cylinder JMGP Series
- Energy Saving
- By Industry ⁄ Process
- Applications
Dual Rod Cylinder JMGP
Air Cylinders ? Dual Rod Cylinders
-
?Cylinder suitable for pushing , lifting , or clamping
?Overall length: Reduced by up to 48% (114mm→59.5mm)
?Weight: Reduced by up to 38% (1.28kg→0.8kg)
?Allowable lateral load: Increased by 6.6 times (0.06kg→0.4kg)
?Non-rotating accuracy: Improved by up to 40% (±0.1°→±0.06°)
?Short pitch mounting is possible.
?3 mounting options:
Top mounting, Bottom mounting, Rear mounting
?Piping is possible in 4 directions.
| Type | Bearing | Series | Action | Bore size (mm) |
|---|---|---|---|---|
| Basic type | Slide bearing | JMGPM | Double acting | 12, 16, 20, 25, 32, 40, 50, 63, 80, 100 |
