Modular F.R.L. Units AC-A
Modular F.R.L./Pressure Control Equipment ? Modular F.R.L.Modular F.R.L. Units ? Modular F.R.L. Units/Air Combination
-
?Easy element replacement
The element and the bowl are integrated. Replacement can be done in
hand.
?Energy-saving regulator Pressure drop: Max. 50% improvement
?Reduced required maintenance space: Max. 46% reduction
?Better visibility&increased safety
The bowl is covered with a transparent bowl guard.
?Attachments:
Spacer: Y200-A, Y300-A, Y400-A, Y500-A
Spacer with bracket: Y200T-A, Y300T-A, Y400T-A, Y500T-A
? The AC20 to 60-A is to be discontinued as of March 2025.
Select the AC20 to 60-D as a substitute.?Click here for details.
The AC10-A will continue to be produced, so it can be selected and used
as before.
| Combination equipment | Series | Port size | Set pressure (MPa) |
|---|---|---|---|
| Air filter, Regulator, Lubricator | AC10 to 40-A | M5，1/8，1/4，3/8，1/2，3/4 | 0.05 to 0.7 0.02 to 0.2 |
| Filter regulator, Lubricator | AC10A to 40A-A | M5，1/8，1/4，3/8，1/2，3/4 | 0.05 to 0.7 0.02 to 0.2 |
| Air filter, Regulator | AC10B to 40B-A | M5，1/8，1/4，3/8，1/2，3/4 | 0.05 to 0.7 0.02 to 0.2 |
| Air filter, Mist separator, Regulator | AC20C to 40C-A | 1/8，1/4，3/8，1/2，3/4 | 0.05 to 0.7 0.02 to 0.2 |
| Filter regulator, Mist separator | AC20D to 40D-A | 1/8，1/4，3/8，1/2，3/4 | 0.05 to 0.7 0.02 to 0.2 |
Air Filter AF-A
Modular F.R.L./Pressure Control Equipment ? Modular F.R.L.Modular F.R.L. Units ? Air Flters/Mist Separators/Micro Mist Separators
-
?Easy element replacement
The element and the bowl are integrated.
Replacement can be done in hand.
?Reduced required maintenance space: Max. 46% reduction
?Better visibility&increased safety
The bowl is covered with a transparent bowl guard.
? The AF20 to 60-A is to be discontinued as of March 2025.
Select the AF20 to 60-D as a substitute. ?Click here for details.
The AF10-A will continue to be produced, so it can be selected and used
as before.
Safety Instructions F.R.L. Units/Precautions Product Selection Guide
Green Procurement (RoHS) Element Part No.
Green Procurement (RoHS) Element Part No.
| Series | Port size | Filtration (μm) |
|---|---|---|
| AF10 to 60-A | M5，1/8，1/4，3/8，1/2，3/4，1 | 5 |
Mist Separator AFM-A
Modular F.R.L./Pressure Control Equipment ? Modular F.R.L.Modular F.R.L. Units ? Air Flters/Mist Separators/Micro Mist Separators
-
?Better visibility & increased safety
The bowl is covered with a transparent bowl guard.
? The AFM-A series will be discontinued in March 2025.
Please select the AFM-D series.?Click here for details.
Safety Instructions F.R.L. Units/Precautions Product Selection Guide
Green Procurement (RoHS) Element Part No.
Green Procurement (RoHS) Element Part No.
| Series | Port size | Filtration (μm) |
|---|---|---|
| AFM20 to 40-A | 1/8，1/4，3/8，1/2，3/4 | 0.3 |
Micro Mist Separator AFD-A
Modular F.R.L./Pressure Control Equipment ? Modular F.R.L.Modular F.R.L. Units ? Air Flters/Mist Separators/Micro Mist Separators
-
?Better visibility & increased safety
The bowl is covered with a transparent bowl guard.
? The AFD-A series will be discontinued in March 2025.
Please select the AFD-D series.?Click here for details.
Safety Instructions F.R.L. Units/Precautions Product Selection Guide
Green Procurement (RoHS) Element Part No.
Green Procurement (RoHS) Element Part No.
| Series | Port size | Filtration (μm) |
|---|---|---|
| AFD20 to 40-A | 1/8，1/4，3/8，1/2，3/4 | 0.01 |
Regulator AR-A
Modular F.R.L./Pressure Control Equipment ? Modular F.R.L.Modular F.R.L. Units ? Regulators
-
?Energy-saving regulator Pressure drop: Max. 50% improvement
? The AR20 to 40-A is to be discontinued as of March 2025.
Select the AR20 to 40-D as a substitute.?Click here for details.
The AR10-A will continue to be produced, so it can be selected and used
as before.
| Series | Port size | Set pressure (MPa) |
|---|---|---|
| AR10 to 40-A | M5，1/8，1/4，3/8，1/2，3/4 | 0.05 to 0.7 0.02 to 0.2 |
Lubricator AL-A
Modular F.R.L./Pressure Control Equipment ? Modular F.R.L.Modular F.R.L. Units ? Lubricators
-
?Better visibility & increased safety
The bowl is covered with a transparent bowl guard.
?Semi-standard specifications: 1000 cm3 tank (AL30 to AL60)
? The AL20 to 60-A is to be discontinued as of March 2025.
Select the AL20 to 60-D as a substitute. ?Click here for details.
The AL10-A will continue to be produced, so it can be selected and used
as before.
| Series | Port size | Bowl capacity (cm3) |
|---|---|---|
| AL10 to 60-A | M5，1/8，1/4，3/8，1/2，3/4，1 | 7 to 135 |
Filter Regulator AW-A
Modular F.R.L./Pressure Control Equipment ? Modular F.R.L.Modular F.R.L. Units ? Filter Regulators
-
?Easy element replacement
The element and the bowl are integrated.
Replacement can be done in hand.
?Energy-saving regulator Pressure drop: Max. 50% improvement
?Reduced required maintenance space: Max. 46% reduction
?Better visibility & increased safety
The bowl is covered with a transparent bowl guard.
? The AW20 to 60-A is to be discontinued as of March 2025.
Select the AW20 to 60-D as a substitute. ?Click here for details.
The AW10-A will continue to be produced, so it can be selected and used
as before.
Safety Instructions F.R.L. Units/Precautions Product Selection Guide
Green Procurement (RoHS) Element Part No.
Green Procurement (RoHS) Element Part No.
| Series | Port size | Set pressure (MPa) | Filtration (μm) |
|---|---|---|---|
| AW10 to 40-A | M5，1/8，1/4，3/8，1/2，3/4 | 0.05 to 0.7 0.02 to 0.2 | 5 |
Modular F.R.L. Units AC-B
Modular F.R.L./Pressure Control Equipment ? Modular F.R.L.Modular F.R.L. Units ? Modular F.R.L. Units/Air Combination
-
?Better visibility and environmental resistance
?Easy element replacement
The element and the bowl are integrated.
Replacement can be done in hand.
?Reduced required maintenance space: Max. 46% reduction
?Regulator: Set pressure 0.05 to 0.85 MPa, 0.02 to 0.2 MPa
?Choose from a selection of pressure gauges:
Square embedded type pressure gauge, Round type pressure gauge, Digital pressure switch
? The AC-B series will be discontinued in March 2025.
Please select the AC-D series.?Click here for details.
| Combination equipment | Series | Port size | Set pressure (MPa) |
|---|---|---|---|
| Air filter, Regulator, Lubricator | AC20 to 60-B | 1/8，1/4，3/8，1/2，3/4，1 | 0.05 to 0.85 0.02 to 0.2 |
| Filter regulator, Lubricator | AC20A to 60A-B | 1/8，1/4，3/8，1/2，3/4，1 | 0.05 to 0.85 0.02 to 0.2 |
| Air filter, Regulator | AC20B to 60B-B | 1/8，1/4，3/8，1/2，3/4，1 | 0.05 to 0.85 0.02 to 0.2 |
| Air filter, Mist separator, Regulator | AC20C to 40C-B | 1/8，1/4，3/8，1/2，3/4 | 0.05 to 0.85 0.02 to 0.2 |
| Filter regulator, Mist separator | AC20D to 40D-B | 1/8，1/4，3/8，1/2，3/4 | 0.05 to 0.85 0.02 to 0.2 |
Regulator AR-B
Modular F.R.L./Pressure Control Equipment ? Modular F.R.L.Modular F.R.L. Units ? Regulators
-
? The AR-B series will be discontinued in March 2025.
Please select the AR-D series.?Click here for details.
| Series | Port size | Set pressure (MPa) |
|---|---|---|
| AR20 to 60-B | 1/8，1/4，3/8，1/2，3/4，1 | 0.05 to 0.85 0.02 to 0.2 |
Regulator with Backflow Function AR□K-B
Modular F.R.L./Pressure Control Equipment ? Modular F.R.L.Modular F.R.L. Units ? Regulators
-
?The regulator with backflow function incorporates a mechanism that exhausts the air pressure in the outlet side quickly.
? The AR-B series will be discontinued in March 2025.
Please select the AR-D series.?Click here for details.
| Series | Port size | Set pressure (MPa) |
|---|---|---|
| AR20K to 60K-B | 1/8，1/4，3/8，1/2，3/4，1 | 0.05 to 0.85 0.02 to 0.2 |
Filter Regulator AW-B
Modular F.R.L./Pressure Control Equipment ? Modular F.R.L.Modular F.R.L. Units ? Filter Regulators
-
? The AW-B series will be discontinued in March 2025.
Please select the AW-D series.?Click here for details.
Safety Instructions F.R.L. Units/Precautions Product Selection Guide
Green Procurement (RoHS) Element Part No.
Green Procurement (RoHS) Element Part No.
| Series | Port size | Set pressure (MPa) | Filtration (μm) |
|---|---|---|---|
| AW20 to 60-B | 1/8，1/4，3/8，1/2，3/4，1 | 0.05 to 0.85 0.02 to 0.2 | 5 |
Filter Regulator with Backflow Function AW□K-B
Modular F.R.L./Pressure Control Equipment ? Modular F.R.L.Modular F.R.L. Units ? Filter Regulators
-
?Integrated filter and regulator units save space and require less piping.
?The filter regulator with backflow function incorporates a mechanism that exhausts the air pressure in the outlet side quickly.
? The AW□K-B series will be discontinued in March 2025.
Please select the AW□K-D series.?Click here for details.
Safety Instructions F.R.L. Units/Precautions Product Selection Guide
Green Procurement (RoHS) Element Part No.
Green Procurement (RoHS) Element Part No.
| Series | Port size | Set pressure (MPa) | Filtration (μm) |
|---|---|---|---|
| AW20K to 60K-B | 1/8，1/4，3/8，1/2，3/4，1 | 0.05 to 0.85 0.02 to 0.2 | 5 |
Filter Regulator AW30/40-X2622
Modular F.R.L./Pressure Control Equipment ? Modular F.R.L.Pneumatic Instrumentation Equipment ? Regulators
-
?Stainless steel 316 and special temperature environment (?40℃) specifications
?Material of external parts: Stainless steel 316
?Ambient and fluid temperatures: ?40 to 80℃
?NACE International Standards compliant
Safety Instructions F.R.L. Units/Precautions Product Selection Guide Automation Example Green Procurement (RoHS)
| Series | Port size | Set pressure (MPa) | Filtration (μm) |
|---|---|---|---|
| AW30/40-X2622 | 1/4，3/8，1/2，3/4 | 0.05 to 0.85 | 5 |
Mist Separator Regulator AWM
Modular F.R.L./Pressure Control Equipment ? Modular F.R.L.Modular F.R.L. Units ? Filter Regulators
-
? The AWM series will be discontinued in March 2025.
Please select the AWM-D series.
Safety Instructions F.R.L. Units/Precautions Product Selection Guide
Green Procurement (RoHS) Element Part No.
Green Procurement (RoHS) Element Part No.
| Series | Port size | Set pressure (MPa) | Filtration (μm) |
|---|---|---|---|
| AWM20 to 40 | 1/8，1/4，3/8，1/2 | 0.05 to 0.85 | 0.3 |
Micro Mist Separator Regulator AWD
Modular F.R.L./Pressure Control Equipment ? Modular F.R.L.Modular F.R.L. Units ? Filter Regulators
-
? The AWD series will be discontinued in March 2025.
Please select the AWD-D series.
Safety Instructions F.R.L. Units/Precautions Product Selection Guide
Green Procurement (RoHS) Element Part No.
Green Procurement (RoHS) Element Part No.
| Series | Port size | Set pressure (MPa) | Filtration (μm) |
|---|---|---|---|
| AWD20 to 40 | 1/8，1/4，3/8，1/2 | 0.05 to 0.85 | 0.01 |
Modular Adapter E210/310/410
Modular F.R.L./Pressure Control Equipment ? Modular F.R.L.Modular F.R.L. Units ? Modular Adapter
-
?Can be easily connected to current products
?Can be freely rotated, thus allowing a wide selection of mounting directions
?Can be connected to current products of different sizes
?Reduced required space/piping maintenance costs
| Series | Port size | Applicable products |
|---|---|---|
| E210 | 1/8，1/4 | Modular F.R.L. equipment (Filters, regulators, lubricators, etc.) 2-port solenoid valve 3-port solenoid valve |
| E310 | 1/4， 3/8 | Modular F.R.L. equipment (Filters, regulators, lubricators, etc.) 2-port solenoid valve 3-port solenoid valve |
| E410 | 1/4， 3/8， 1/2 | Modular F.R.L. equipment (Filters, regulators, lubricators, etc.) 2-port solenoid valve 3-port solenoid valve |
Conforming to OSHA Standard: Pressure Relief 3 Port Valve with Locking Holes VHS
Directional Control Valves ? Finger Valve/Hand Valves/Residual Relief 3 Port ValveModular F.R.L./Pressure Control Equipment ? Modular F.R.L.
Modular F.R.L. Units ? Pressure Relief 3 Port Valves
-
?Compliant with OSHA Standards (Occupational Safety and Health
Administration Department of Labor)
?This manually operated valve can be used to prevent accidents caused by
residual pressure in pneumatic lines.
?The supply and exhaust status of air flow can be confirmed at a glance.
?When in the exhaust position, the valve may be padlock secured. This can
prevent accidental start-ups while personnel are cleaning or servicing
equipment.
?Push the knob and then turn. This 2-step action can prevent
malfunctions.
? The VHS series will be discontinued in March 2025.
Please select the VHS-D series.
?Click here for details.
Safety Instructions 3/4/5 Port Solenoid Valves/Precautions Selection/Technical Data
Green Procurement (RoHS)
Green Procurement (RoHS)
| Series | Description | Knob operation | Port size |
|---|---|---|---|
| VHS20 | Pressure relief 3-port valve with locking holes | Single action | 1/8，1/4 |
| VHS30 | Pressure relief 3-port valve with locking holes | Single action | 1/4，3/8 |
| VHS40 | Pressure relief 3-port valve with locking holes | Single action | 1/4，3/8，1/2，3/4 |
| VHS50 | Pressure relief 3-port valve with locking holes | Single action | 3/4，1 |
| VHS2510 | Pressure relief 3-port valve with locking holes | Double action | 1/8，1/4 |
| VHS3510 | Pressure relief 3-port valve with locking holes | Double action | 1/4，3/8 |
| VHS4510 | Pressure relief 3-port valve with locking holes | Double action | 1/4，3/8，1/2，3/4 |
| VHS5510 | Pressure relief 3-port valve with locking holes | Double action | 3/4，1 |
Modular Connection Type Residual Pressure Relief 3 Port Solenoid Valve VP500/700
Modular F.R.L./Pressure Control Equipment ? Modular F.R.L.Modular F.R.L. Units ? Pressure Relief 3 Port Valves
-
?For connecting to F.R.L. units (AC-A Series)
?Allows for space saving and reduced piping labor
?Power consumption: 0.35 W (Without light)
Safety Instructions 3/4/5 Port Solenoid Valves/Precautions Selection/Technical Data
Green Procurement (RoHS)
Green Procurement (RoHS)
| Series | Applicable combinations |
|---|---|
| VP500 | AC25-A，AC30-A |
| VP700 | AC40-A |
Centering Unit MACM
Air Cylinders ? Pin Shift Cylinder
-
?Alignment and positioning of transferred workpieces
Contributes to space saving on conveyor lines
?Table
Max. allowable load weight: 1000 kg (MACM10)
Workpieces can be moved in any direction: forward/backward, right/left, at an angle, and even rotated (360o).
Ball bearings allow for smooth operation.
Table centering accuracy ±1 mm or less (Workpiece not loaded)
Table center movable range Max. ?100 mm (MACM10-50)
| Series | Action | Max. allowable load weight kN | Stroke (mm) |
|---|---|---|---|
| MACM | Double acting | 2, 4, 6, 10 | 12, 20, 30, 50 |
Soft Start-up Valve AV
Modular F.R.L./Pressure Control Equipment ? Modular F.R.L.Modular F.R.L. Units ? Soft Start up Valves
-
?A starting valve that can supply air at a low speed and exhaust it at a high speed by blocking the air supply
| Series | Port size | Operating pressure (MPa) |
|---|---|---|
| AV2000 to 5000 | 1/4，3/8，1/2 | 0.1 to 1 |
Large Flow Air Filter AF
Modular F.R.L./Pressure Control Equipment ? Modular F.R.L.Modular F.R.L. Units ? Air Flters/Mist Separators/Micro Mist Separators
| Series | Port size | Filtration (μm) |
|---|---|---|
| AF800/900 | 1 1/4，1 1/2，2 | 5 |
